JL HDPE — HEAVY-DUTY WATER TRANSPORTWater Mains That
Water Mains That
Never Corrode
PE100 HDPE pipes for agriculture, irrigation and mainline water supply — flexible, UV-stable, and built to carry pressure for decades underground or in the open sun.
☀️
UV Stabilised
Carbon-black PE100 resin withstands years of direct tropical sun exposure.
🌾
Built for Agriculture
The standard choice for irrigation, drip-feed and farm water mains.
🔄
Flexible Coils
Coiled supply for small diameters — fewer joints, faster field installation.
💪
High Pressure Rated
PE100 resin rated up to PN16 for reliable mainline water transport.
DIMENSIONS & PRESSURE RATING
Full Size Range, PE100 Grade
Manufactured to ISO 4427 from PE100 resin — coiled for easy field runs, straight lengths for larger mains.
| Outer Diameter | Pressure Class | Supply Form |
|---|---|---|
| 20mm | PN16 | Coil (100m) |
| 25mm | PN16 | Coil (100m) |
| 32mm | PN16 | Coil (50m) |
| 40mm | PN16 | Coil (50m) |
| 50mm | PN10 | Coil (50m) / Straight (6m) |
| 63mm | PN10 | Straight (6m) |
| 75mm | PN10 | Straight (6m) |
| 90mm | PN10 | Straight (6m) |
| 110mm | PN10 | Straight (6m) |
